Technical data
Protection degree
IPX4
Protection class
I
Nominal voltage
230 V AC
Mains frequency
50 Hz
Power consumption
2000 W
Power consumption standby
≤ 0.5 W
Flow pressure
0.5-10 bar
Operating temperature
5–40 °C
Water temperature, adjustment range
34–40 °C
Calculated flow rate
0.03 l/s
Minimum flow pressure for calculated flow rate
0.5 bar
Spray time
30-50 s
Maximum load WC seat
150 kg
Application purposes
For convenient and odourless toilet use
For gently cleaning the anal and vaginal areas with water
Characteristics
Hybrid hot water system with continuous flow heater and storage water heater
Anal shower with double-nozzle WhirlSpray shower technology
Separate Lady shower nozzle in protected park position
Adjustable shower water temperature
Spray intensity can be set to five different levels
Spray arm can be set to five different positions
Adjustable oscillating spray (automatic forward and reverse motion of the spray arm)
Automatic pre- and postrinsing of the spray nozzle with fresh water
Descaling programme
Rimless WC ceramic appliance featuring TurboFlush flush technology
Washdown WC with special glaze KeraTect
User detection
Odour extraction with ceramic honey comb filter can be activated
Odour extraction unit with run-on function
Dryer can be activated
Dryer air intensity can be set to 5 positions
Dryer arm can be extended
Adjustable dryer temperature
WC seat ring with rapid heating function
Adjustable temperature of the WC-seat heating
WC seat ring and WC lid with soft-closing mechanism
WC lid with SoftOpening
Touchless opening and closing of the WC lid
Activation of the orientation light when aproaching
Orientation light can be set in seven colours
Functions and settings via remote control
Four user profiles can be programmed
Compatible with Geberit Home App
Water supply connection on the left, hidden behind the WC ceramic
Mains connection with flexible three-core sheathed cable, on the right side, hidden behind the WC ceramic
External water supply connection on the left possible with accessories
External mains connection with power outlet on the right possible
Premounted sound insulation
Approval in accordance with (DIN) EN 1717 / (DIN) EN 13077
Scope of delivery
Water supply connection set for Sigma and Omega concealed cisterns 12 cm, installation height 112 cm
Female socket for mains connection
Spray shield
Descaling agent, 125 ml
Cleaning set
Connection set for WC, ø 90 mm
Remote control with wall-mounted case and battery CR2032
Fastening material
